MF59 3470 Precision NTC Thermistor 2800K-5000K Glass Sealed

Name: MF59 3470 Precision NTC Thermistor 2800K5000K Glass Sealed
Brand: Hefei Minsing
Price: 1 USD

Brand Name : Hefei Minsing

Model Number : MF59

Certification : UL,REACH, ROHS

Place of Origin : China

MOQ : 500pcs

Price : Negotiable

Payment Terms : T/T

Supply Ability : 5Million Pieces Per Year

Delivery Time : 7-10 work days

Packaging Details : Bulk

Name : Precision NTC Thermistor

Type : MF59 3470

Head Size : Φ1.5mm

Wire Length : 3.6mm

R25℃ : 0.3KΩ-1500KΩ

B Value : 2800K-5000K

R Tolerance : 1%,2%,3%,5%,10%

B Tolerance : 1%, 2%,3%,5%

Contact Now

MF59 3470 Precision NTC Thermistor 2800K-5000K Glass Sealed

Product Feature:

Glass encapsulated / Heat-resistant / Stable capability

Application:

1. Heater, Warmer, Automobile air conditioners, Refrigerators, Freezers,
2. Water heaters, Gas boiler, Electric kettles, Wall-hung gas boiler, Water dispensers,
3. Toaster, Microwave oven, Air dryer, Roasting pan, Induction cooker, Electric hot plate,
4. Iron, Garment steamer, Hair straighten, Coffee maker, Coffee pot,

MF59 3470 Precision NTC Thermistor 2800K-5000K Glass Sealed Specification Explain:

SJ MF 59 -3470 -103 J

① ② ③ ④ ⑤ ⑥

① Minsing Co.,Ltd

② NTC thermistor

③ Glass sealing type MF59 series

④ B value(B 25/50℃) Example: 3470:B 25/50℃: 3470

⑤ Standard resistance value at 25℃(R25℃):

Example:502:R25℃ 5KΩ,103:R25℃ 10KΩ ,104:R25℃ 100KΩ

⑥ R25℃ interchangeability precision:

F(±1%); G(±2%); H(±3%); J(±5%); K(±10%)

Specification:

Specification

R25℃ (KΩ)

B25/50℃ (K)

Disspation constant

Thermal time constant

OperatiNG temp. range

SJMF59

0.3~1500

2800~5000

Approx.2mW/℃

Approx.8s

-40～+250℃
